Characteristics:

The Rugby PRO rolling screen has been designed for the professional channel, where ease of installation, durable materials and simplicity of use are required.

In this product line, the heads and lower bar are made of laminated iron to make the screen extremely robust.
The aluminium case has been designed with an innovative interlocking system that reduces the transmission of vibrations from the motor, limiting the noise when operating the screen.
The fixing system has been completely innovated and allows symmetrical installation with both front and back screen fall.

In the Rugby range, rollers of different diameters are used based on the size of the projection viewing area. Rolls of 90mm are mounted on sizes over 2500mm and up to 4500mm of viewing area width.
In the non-tensioned version, the Rugby PRO is available with or without edges.
Case and lower bar are available in matt white or matt black. Back fall for the surface is the standard. Front and reverse-roll are also available as options.
Motor is on the right side (standard). It can also be ordered on the left side (optional).

Softend Lowbar System Designed using soft gaskets that dampen noise and absorb contacts when closing the lower bar.	SuperQuick Bracket Attachment System The screen is supplied with an improved rapid and user-friendly fixing system for both wall and ceiling mounting. The clamping has been designed adopting symmetrical logics to enable both front and back mounting. The bracket kit consists of a single fixing unit (extruded aluminium bracket) and a single clamping unit (PVC moulded block), significantly reducing the number of parts.
Rugby PRO lowbar detail	Screen with mechanical motor and radio receiver installed inside the casing (the receiver is not inside of the motor, like with a standard radio-integrated motor).

Create your own screen with PSS (Personal Screen System):

• Personalized dimensions: width and height
• Motor type: standard motor or optional motor with RF receiver integrated in the casing
• Case: with quick-installation system
• Case color: standard in White Matte. Optional in Black Matte. Custom color for an extra cost
• Standard Drop: from 5 to 45 cm
• Projection surface fall: back (standard), front or reverse-roll (optional)
• Side of command/motor: right (standard) or left (optional)
• Projection Surfaces: Reference White 2, Reference Grey 2, Ambient Grey 2, Vision White, Vision White Pro, Vision Acoustik, Vision Rear DB solo per versione non bordata, Chroma Key only without black borders
• Aspect ratios:1:1 - 4:3 - 16:10 - 16:9 - 2.35:1 - 2.37:1 - 2.39:1 - 2.40:1
